3.6 OTHER Setup Pages
4.
Select the Lock Keypad check box if you want to lock the front panel keypad. [DEFAULT
= unlocked (unchecked)]
5.
Deselect the Allow Position Display checkbox if you do not want to enable the option to
display position data on the front panel information display. See also
play
3.6.8.3 Locking/Unlocking the Front Panel Keypad
To lock or unlock the keypad on the front panel of the unit (see illustration
1.
Navigate to the MANAGEMENT/OTHER/Front Panel configuration window.
2.
Depending on whether you want to enable or disable the keypad, check or uncheck the
Lock Keypad checkbox.
3.
Click the Submit button or the Apply button at the bottom of the window.
3.6.8.4 Enabling/Disabling the Position Display Screen
To enable or disable [DEFAULT = enable] the option to display geographic position data on the
information display, if so configured (see also
1.
Navigate to the MANAGEMENT/OTHER/Front Panel configuration window.
2.
Check or uncheck the Allow Position Display checkbox.
3.
Click the Submit button or the Apply button at the bottom of the window.
3.6.9

Backing-up and Restoring Configuration Files

Once SecureSync has been configured, it may be desired to back up the configuration files to a PC
for off-unit storage. If necessary in the future, the original configuration of the SecureSync can then
be restored into the same unit.
182
NOTE – With Timescale configured as "Local" and during DST (Daylight Saving
Time, as configured in the Local Clock), a "DST indicator" (decimal point) will be dis-
played to the bottom-right of the minutes portion of the LED time display. The "DST
indicator" extinguishes during "Standard" time. If the Local Clock is configured as
"No DST/Always Standard Time", the DST indicator won't ever be lit.
.
NOTE – If the keypad is unlocked, pressing any keypad key will temporarily return
the information display to the "Home" menu display for keypad operation. One
minute after the last keypad press, the information display will return to its con-
figured screen.
Allow Position Display
CHAPTER •
3 SecureSync User Reference Guide Rev. 18
Allow Position Dis-
Front Panel
):
):
