Spectracom SecureSync User Reference Manual page 340

5.2 Time and Frequency Option Cards
All outputs are listed, displaying their current output states. For a listing of the states, see "CTCSS
Outputs: Edit Window" below, and "Alarm Outputs: Edit Window" on page 326.
To view the settings of
For instructions, see: "Viewing the Configuration of an Input or Output" on page 288.
The Web UI list entry for this card is named: Simulcast .
Figure 5-20:
5.2.7.4 CTCSS Outputs: Edit Window
To configure a CTCSS output , go to its Edit window. For instructions, see: "Configuring the Set-
tings of an Input or Output" on page 290.
The Web UI list entry for this card is named: Simulcast .
324
one
of the Alarm Outputs or CTCSS Outputs , go to its Status window.
NOTE – Alarm Output 0 through Alarm Output 3 are reserved by SecureSync. Num-
bering for alarm outputs from the option card will begin at Alarm 4, which is available
on the DB-9 output, while Alarms 5 and 6 are assigned to the RJ-12 connector.
Simulcast Alarm Output Status window
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
