5.6.1.3 Alarm Relay Output: Edit Window
To configure the Alarm Relay Output, go to its Edit window. For instructions, see: "Configuring the
Settings of an Input or Output" on page 290.
The Web UI list entry for this card is: Relay Output . The name of the output is: Alarm Output
[number].
The Edit window allows the configuration of the following settings:
5.6.1.4 Alarm Relay Output: Status Window
To view the current settings of an Alarm Relay Output, go to its Status window. For instructions,
see: "Viewing the Configuration of an Input or Output" on page 288.
The Web UI list entry for this card is: Relay Output . The name of the output is: Alarm Output
[number] .
CHAPTER •
5 SecureSync User Reference Guide Rev. 18
NEVER OUTPUTS
OUTPUTS ON MINOR ALARM
OUTPUTS ON MAJOR ALARM
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
Alarm Type :
None—Will not output for an alarm.
Minor—Will output on a minor alarm.
Major—Will output on a major alarm.
NOTE – SecureSync starts numbering I/O ports with 0 (only 1PPS and 10 MHz out-
puts start at 1, because of the built-in outputs).
