4. Aztec code is settable within the range (00H – FFH).
For Binary data, user needs to set the data number properly by using the <ESC>DN command. If Data number and
Print data doesn't match, symbol will not print properly.
5. When print data is [1BH], specify [1BH,1BH]. Data number becomes [0002].
6. Use [1BH,*] in pairs within input data when presenting ECI . '*' must be a value between 31H and 36H. The number in
the following FLG(1) - FLG(6) are the number of digits of the data to be used for ECI.
<ESC>1→FLG(1) The number of digits specified for ECI data is 1 digit.
<ESC>2→FLG(2) The number of digits specified for ECI data is 2 digits.
<ESC>3→FLG(3) The number of digits specified for ECI data is 3 digits.
<ESC>4→FLG(4) The number of digits specified for ECI data is 4 digits.
<ESC>5→FLG(5) The number of digits specified for ECI data is 5 digits.
<ESC>6→FLG(6) The number of digits specified for ECI data is 6 digits.
e.g.)A sample data with <ESC>4 : <ESC>41111ABCDE
The scanned data when <ESC>4 will be "¥001111ABCDE" ( '¥' may differ depending on scanner settings).
1) <ESC>4 means FLG(4). The succeeding "1111"(4 digits) will be treated as ECI data.
2) Since it is short by 2 digits, 0 is padded in the beginning to make it "¥001111".
7. The message ID is enabled only when it is separated to print after automatic setting with "Number of symbols for
structured append" with specifying "Append structured blocks".
Aztec Code Table
b8 0
b7 0
b6 0
b5 0
B4 b3 b2 b1
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
0 0 1 1 3
0 1 0 0 4
0 1 0 1 5
0 1 1 0 6
0 1 1 1 7
1 0 0 0 8
1 0 0 1 9
1 0 1 0 A
1 0 1 1 B
1 1 0 0 C
1 1 0 1 D
1 1 1 0 E
1 1 1 1 F
S I
0 0 0 0 0
0 0 0 1 1
0 1 1 0 0
1 0 1 0 1
0 1 2 3 4 5
@ P ｀
SP 0
! 1 A Q
"
2 B R
# 3 C S
$ 4 D T
% 5 E U
& 6 F V
'
7 G W
( 8 H X
) 9 I Y
* : J Z
+ ; K [
＼
, < L
- = M ]
. > N ^
/ ? O _
209
S
0 0 1 1 1 1
1 1 0 0 0 0
1 1 0 0 1 1
0 1 0 1 0 1
6 7 8 9 A B
p
a q
b r
c s
d t
e u
f v
g w
h x
i y
j z
k {
l
m }
n ~
o
DEL
O
1 1 1 1
1 1 1 1
0 0 1 1
0 1 0 1
C D E F
