H3C S3100 Series Ethernet Switches
Table 2-10 Description on the fields of display cluster base-members
SN
Device
MAC Address
Status

2.4.3 display cluster base-topology

Syntax
display cluster base-topology [ mac-address mac-address | member member-id ]
View
Any view
Parameters
mac-address mac-address: Displays the structure of the standard topology three
layers above or below the node specified by the MAC address.
member member-id: Displays the structure of the standard topology three layers above
or below the node specified by the member ID.
Description
Use the display cluster base-topology command to display the standard topology of
the cluster.
The standard topology of a cluster refers to the topology saved through the topology
save-to command. The standard topology is the backup of the normal topology
information of a cluster and is mainly used to resume the normal topology of the cluster
member devices in case the cluster topology encounters a fault.
Examples
# Display the standard topology of the cluster.
<aaa_0.Sysname> display cluster base-topology
--------------------------------------------------------------------
(PeerPort) ConnectFlag (NativePort) [SysName:DeviceMac]
--------------------------------------------------------------------
[aaa_0.Sysname:000f-e202-2180]
|
Field
2-47
Chapter 2 HGMP V2 Configuration
Description
Device number in the cluster
Device name
Device MAC address
Device status
Up: The member is connected.
Down: The member is disconnected.
