Show Instrument Schematic - Micromeritics ASAP 2020 Confirm Operator's Manual

Degas
Servo Valve
Heaters
Status window

Show Instrument Schematic

Displays the schematic (shown in the previous section) for the SmartVac.
202-42811-01 - Mar 2011
Table 5-2. Degasser Valves
Valve
D1 and D2
D5
D6
D7
Actions: Set, Close
Set displays the Servo Valve Settings dialog so that you can
enter a target pressure for sample evacuation. This feature
enables you to use the software to bring down the sample
pressure slowly and incrementally.
Close closes the servo valve.
Actions: Set, Disable
Set displays the Port [n] Heater Settings dialog so that you
can specify a ramp rate and target temperature. After you
click and close the dialog, the settings are displayed directly
below the heater symbol.
Disable cancels the settings.
Displays the status of the current degassing operation(s).
Refer to Show Status, page
window.
ASAP 2020 Confirm
Description
Sample port valves
Vacuum valve
Servo isolation valve
Gas inlet port valve
5-13 for information on this
5-27
