New
Show graphic
Overlays
Edit
202-42811-01 - Mar 2011
Select this option to have a graphic display above the report
title. The graphic can be in a bitmap (bmp) or an enhanced
metafile (emf) format. For example, you may wish to display
your company logo. Click
then use the height and width fields to specify the size. The
image can also be edited from the report window.
Displays the Graph Overlay Samples dialog so that you can
choose the sample files containing the data you wish to
overlay onto a selected plot.
Click
to the right of the sample number field(s) to
Browse
choose the desired file(s). Use
entry. You can select up to eight files.
After choosing the desired files, be sure to edit the type of
graph you are overlaying and choose the Overlay samples
option. Refer to
OPERATIONAL
1
for step-by-step instructions on generating overlays.
Allows you to edit parameters of the selected report. This
push button is disabled for the Options and Sample Log
Reports.
ASAP 2020 Confirm
to choose the graphic,
Browse
to clear a field of its
Clear
PROCEDURES, page
3-
4-35
