Specifications

Specifications
The ASAP 2020 system has been designed and tested to meet the specifications provided
below.
Characteristic
Range:
Resolution:
1000-mmHg Transducer
10-mmHg Transducer*
1-mmHg Transducer**
(optional for high stability)
0.1-mmHg Transducer***
(optional for high stability)
Accuracy (Analysis system only):
Includes nonlinearity, hysteresis, and nonrepeatability. Transducer manufacturer's
specifications.
1000-mmHg Range
10-mmHg Range*
1-mmHg Range**
0.1-mmHg Range***
Vacuum Pump:
High Vacuum Pump:
(if installed)
Ultimate vacuum measured by pump manufacturer according to Pneurop Standard 5608.
Type:
Accuracy:
*High Vacuum systems
**Micropore systems
***Micropore systems with 0.1 mmHg
202-42811-01 - Mar 2011
PRESSURE MEASUREMENT
0 to 950 mmHg
0.001 mmHg (Analysis system)
1 mmHg (Degas system)
0.00001 mmHg
0.000001 mmHg
0.0000001 mmHg
Within 0.15% of reading
Within 0.15% of reading
Within 0.12% of reading
Within 0.15% of reading
VACUUM SYSTEM
Mechanical, two-stage, for analysis; optional for degas.
Ultimate vacuum 5 x 10
for systems equipped with optional High Vacuum pump.
Less than 3.8 x 10
MANIFOLD TEMPERATURE TRANSDUCER
Platinum resistance device (RTD)
0.02 ºC (by keyboard entry)
ASAP 2020 Confirm
Specification
-3
mmHg. Dry pumps available
mmHg
-9
1-5
