Controls, Indicators, and Connectors

Rear Panel

Vacuum pump recess
202-42811-01 - May 2012
Vacuum Pump
Location
Provides for placement of the vacuum pumps; two are
required. Vacuum pumps can be serviced from the front of
the instrument by removing the vacuum pump panel
located on the lower left side of the front panel. Refer to
Front Panel 2-2.
, page
ASAP 2020 Confirm
2-7
