Generating Graph Overlays

Multiple Samples Overlay

1. From the main menu bar, select File > Open > Sample Information to display the Open
Sample Information File dialog box.
2. Select a sample on which to overlay graphs of other samples, then click
Information dialog is displayed.
3. Click the Report Options tab to display the Report Options dialog.
4. Make your report (or graph) selections, adding or deleting as you choose.
5. Choose the type of report for which you wish to generate overlays, click
the steps listed for that report:
If you are overlaying this
type of report....
Isotherm
202-42811-01 - Mar 2011
Then ....
Select the desired plot(s) from the Select Reports group
box.
Click (becomes enabled when the plot is
Options
selected) adjacent to the selected plot
Select the Overlay samples check box, then click
Click again to return to the Report Options dialog..
OK
ASAP 2020 Confirm
; the Sample
Open
, and perform
Edit
.
OK
3-35
