F-Ratio Plot - Micromeritics ASAP 2020 Confirm Operator's Manual

New
From/To fields

f-Ratio Plot

The f-Ratio report allows you to take the measured isotherm and normalize it using a
reference isotherm.
Reference Isotherm
Browse
202-42811-01 - Mar 2011
Enabled when you choose not to autoscale data (deselect the
Autoscale option), allowing you to specify the beginning and
ending ranges of the X- and/or Y-axis. Data collected outside
these ranges are not included in the plot.
The X-Axis Range fields show the relative pressure
The Y-Axis Range fields show the quantity of gas adsorbed
Displays the sample file you choose as a reference. You
should always choose a file containing an isotherm measured
from a non-porous sample of the same material as the current
sample.
Click to choose the sample file you wish to use as a reference
for the isotherm.
ASAP 2020 Confirm
4-59
