Unit Configuration
Configuration
Software Versions
SmartVacSoftware
Versions
Features
Gas
202-42811-01 - Mar 2011
Displays the following:
• The hardware code specifying the hardware components
(for example transducers) present in your analyzer. This
code is provided so the Service Department may quickly
identify your hardware configuration and provide prompt
assistance. Hardware codes translate as follows:
E = 1000-mmHg transducer
G = 10- and 1000-mmHg transducers
H = 1-, 10-, and 1000-mmHg transducers
• The identification number of the port being used to con-
trol the analyzer.
• The serial number of the attached analyzer (active unit).
The software versions of the MIC BIOS, Controller, and
ASAP 2020 System software.
The software versions of the MIC BIOS and SmartVac
software. This group box is not displayed if the SmartVac is
not installed.
The options currently enabled on your system (for example,
MicroPore or MultiGas).
Displays the Gas Configuration dialog.
This dialog allows you to choose the gases attached to each
port of the analyzer.
