Axis Cross Hair

A cross-hair function is available so that you can view axis coordinates. To use this feature,
simply left-click in the desired area of the graph.
X-axis position
Right-click in the graph area and choose Autoscale or Redraw from the shortcut menu to
remove cross-hair lines and return to the normal view. Alternatively, you can click outside of
the graph area.

Report Examples

The remainder of this chapter contains samples of some of the reports that can be generated
by the ASAP 2020 Confirm Program. Most of the reports can be varied through entries on the
report options screens.
6-28
Point of Coordination
Report Examples
Y-axis position
