Collected/Entered Data - Micromeritics ASAP 2020 Confirm Operator's Manual

New

Collected/Entered Data

If you choose Manually entered as the type of data in the Sample Information dialog, an
Entered tab is added allowing you to enter the data.
If you choose Automatically collected as the type of data in the Sample Information dialog,
a Collected Data tab is added when analysis is complete. The Collected Data dialog will
contain the data points collected during analysis and the specified calculation assignments.
This example shows the Collected Data dialog from a completed sample information file; the
Entered dialog is identical except the data is entered and the tab displays as Entered Data.
Pressure table
202-42811-01 - Mar 2011
For collected data, columns for the following are displayed:
• absolute pressure
• relative pressure
• quantity adsorbed
• outliers (if Use calculation assignments is not selected)
• calculation assignments for each requested report option
(if Use calculation assignments is selected)
For entered data, columns for the following are displayed:
• absolute or relative pressure (depending on the selection
in the Pressures group box)
• quantity adsorbed
ASAP 2020 Confirm
4-91
