Show Instrument Schematic - Micromeritics TRISTAR II PLUS Operator's Manual

Analyzer Schematic Components
Schematic
Description
Components
Sample ports
1-3
P port
4
0
Servo valve
5
Isolation valve
6
Inlet valves
7,8,9,14
Vacuum
10
Unrestricted vacuum sample ports
11-13
Schematic Shortcuts
Icon or Symbol
Valve options
Elevator options
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
Description
Open. Opens the selected valve.
Close. Closes the selected valve.
Pulse. Use to quickly turn the valve on and off allowing the operation to
proceed in small increments.
For Servo valve:
Set. Use to set the servo valve target pressure and dose or evacuate.
n
Open. Opens the servo valve. The valve symbol changes to green.
n
Close. Closes the servo valve. The valve symbol changes to solid
n
black.
Right-click the elevator icon, then select:
Raise. Select Raise to raise the elevator. When it is moving, press the
keyboard space bar to stop the movement (or right-click and select Stop
from the menu).
Lower. Select Lower to lower the elevator. When it is moving, press the
keyboard space bar to stop the movement (or right-click and select Stop
from the menu).
Stop. Stops the elevator from moving.

Show Instrument Schematic

2 - 21
