Volume - Micromeritics ASAP 2020 Confirm Operator's Manual

Calibration

Volume

Use this option to calibrate the system volume; the Calibrate System Volume dialog is
displayed.
Displays as Next if you
choose Measured.
The system volume typically is calibrated after servicing valves, transducers, or any part of
the analysis plumbing. The ASAP 2020 must be idle to calibrate system volume. Before you
calibrate system volume, calibrate the manifold temperature sensor and the master pressure
gauge.
Previous
Entered
Measured
Done
Next
202-42811-01 - Mar 2011
Retains the values currently in use.
Allows you to enter values to use.
Allows you to measure the system and lower manifold vol-
umes using a reference volume (in an ice bath) of known
value.
Closes the dialog; displays for the Previous and Entered
selections.
Advances you to the next view of the Calibrate System Vol-
ume dialog; displays for the Measured selection.
ASAP 2020 Confirm
5-23
