Installing Dewars

Analysis Dewar

1. Fill the analysis Dewar with the analysis bath fluid to about 5-cm (2-in.) from the top.
Incorrect fluid levels can lead to measurement errors. Do not overfill the Dewar.
2. Check the analysis bath fluid level with the dipstick as shown below.
3. Insert the analysis Dewar onto the elevator as shown in the following illustration.
Analysis Dewar
Elevator
202-42811-01 - Mar 2011
Analysis Dewar
ASAP 2020 Confirm
Maximum Level
Indicator Mark
Wetness or frozen
condensation indicates
bath liquid level.
