Micromeritics ASAP 2020 Confirm Operator's Manual page 131

New
Pressure Range
Fitted Thickness Range
Surface area correction
factor
Tabular report
t-Plot
Overlay samples
202-42811-01 - Mar 2011
Displays the Report Relative Pressure Range dialog so that
you may specify minimum and maximum relative pressures
to use with this report.
• If Use calculation assignments is not selected on the Col-
lected/Entered dialog, all of the nonoutlier points of the
collected data within the specified range are used for calcu-
lating the data for this report.
• If Use calculation assignments is selected, collected data
points which are assigned to this report type are used.
Provides two fields, allowing you to enter the minimum and
maximum thicknesses you wish to include in the thickness
curve.
This value corrects for surface areas that are not smooth and
brings the values for BET surface area and micropore surface
area into accordance. For most samples, the default value of
1.000 is adequate
Select this option to generate a table of collected data.
Select this option to generate a graphical representation of the
collected data.
Allows you to overlay data from the current sample file with
data from other sample files. The other sample files are
chosen by clicking
Overlays
screen.
ASAP 2020 Confirm
on the main Report Options
4-55
