ASAP 2020 Confirm
Tabular Report
The Tabular report enables you to customize your report with one to six columns of data for
Astakhov reports and one to five columns of data for Radushkevich reports. The Dubinin
Tabular Report Column Options dialog box is displayed.
The default column title appears next to the column number. Each column includes a drop-
down list of the data types to include in the report.
Transformed Isotherm
The Transformed Isotherm report allows you to restrict the line fit to a portion of the
isotherm. The Dubinin Transformed Isotherm Plot Options dialog box is displayed.
Overlay Samples
Autoscale x-axis
Autoscale y-axis
4-82
Select this option to overlay the current plot with data from
other samples. Then click
dialog to choose the sample files.
Select these options to have the X- and/or Y-axes
automatically scaled. Both X- and Y-axes begin at zero, and
the system uses the highest values collected during analysis
as the ending points for axes ranges.
on the Report Options
Overlays
