ASAP 2020 Confirm

Pressure Scale

Use this option to adjust the scale of the transducer to match a reference standard; the Cali-
brate Pressure Scale dialog is displayed.
A Pressure Scale option will be available for each type of transducer you have installed. For
example, if you have the 1000-mmHg and the 10-mmHg transducers installed, a Pressure
Scale option is displayed for the adjustment of each one.
Reset to nominal
Match to entered pressure

Temperature

Use this option to adjust the offset of the manifold temperature sensor to agree with a value
obtained using a calibration device. The Calibrate Manifold Temperature dialog is displayed
so that you may enter the measured value.
5-22
Restores factory calibration settings for all transducers.
Select this option to enter a value obtained using a pressure
gauge to determine the actual manifold pressure
Calibration
202-42811-01 - Mar 2011
