Micromeritics ASAP 2020 Confirm Operator's Manual page 125

New
Temkin isotherm plot
Overlay samples
Autoscale x-axis
Autoscale y-axis
From/To fields
202-42811-01 - Mar 2011
Overlays the Temkin isotherm with the analysis data.
Choose this option to overlay Freundlich isotherm data from
the current file with the same type of data from other samples
(files). The desired files are chosen by selecting
the Report Options dialog.
Select these options to have the X- and/or Y-axis scaled
automatically.
Both X- and Y-axes begin at zero; the system uses the
highest values collected during analysis as the ending points.
The X-axis shows the natural log of absolute pressure and
the Y-axis shows the quantity of gas adsorbed.
If you choose not to autoscale data, the From and To fields
are enabled, allowing you to enter the ranges.
Enabled when you choose not to autoscale data (deselect the
Autoscale option), allowing you to specify the beginning and
ending ranges of the X- and/or Y-axis. Data collected outside
these ranges are not included in the plot.
ASAP 2020 Confirm
on
Overlays
4-49
