Micromeritics ASAP 2020 Confirm Operator's Manual page 159

New
Autoscale x-axis
Autoscale y-axis
(continued)
Pore Volume
When you select the dV/dw Pore Volume plot from the Dubinin Report Options dialog, the
Dubinin dV/dw Pore Volume Options dialog is displayed.
The Pore Volume report is unavailable if you choose Radushkevich as the type of
report.
Plot options
Overlay Samples
202-42811-01 - Mar 2011
If you choose not to autoscale data for either (or both) axis,
the adjacent fields are enabled so that you may enter a
beginning and ending value. Data collected outside these
ranges are not included in the plot.
The X-Axis Range fields show the quantity of gas adsorbed
at standard temperature and pressure.
The Y-Axis Range fields show the log of relative pressure.
Data ranges are displayed in the information bar across the
bottom of the dialog when the cursor is in a numerical data
entry field.
You can plot data with a curve, points, or both.
Select this option to overlay data from other samples. Then
click on the Report Options dialog to choose the
Overlays
files.
ASAP 2020 Confirm
4-83
