Enable Manual Control
The remainder of the components are displayed for informational purposes only; they cannot
be controlled manually.
Temperature
Transducers
Vacuum Gauge
202-42811-01 - Mar 2011
Represents the sample tube.
Represents the Psat tube.
This group of rectangles on the left side of the schematic dis-
plays the temperature, the vacuum gauge pressure, and the
transducer(s) currently installed. This representation shows
all three transducers installed.
ASAP 2020 Confirm
5-11
