ASAP 2020 Confirm
Calibrate Vacuum Gauge
Displays the Calibration Vacuum Gauge dialog containing the current vacuum level.
This dialog also allows you to enter a new calibration value (if necessary) obtained using an
external reference gauge.
Calibrate Servo
Use this option to calibrate the servo valve to the manifold pressure transducer. The servo
valve should always be recalibrated after a pressure calibration has been performed. The Cal-
ibrate Servo Valve dialog is displayed.
Start
5-30
Begins the calibration. The servo valve is used to evacuate
and equilibrate the manifold. The pressure transducer read-
ings are used to calibrate the servo set point. Status messages
are displayed during this procedure, then the dialog closes
automatically.
Degas
202-42811-01 - Mar 2011
