Show Instrument Schematic
Show Instrument Schematic
Unit [n] - Show Instrument Schematic
Use to display an analyzer schematic. To operate the valves and elevator from this window, Manual
Controls must be enabled (Unit [n] > Enable Manual Control).
Displays only if the Krypton option is installed
Refer to
Enable Manual
Valve State
6-12
Control, page
for additional details on this schematic.
6-8
Green indicates an open valve.
White indicates a closed valve.
Description
302-42828-01 - Dec 2012
TriStar II 3020
