Controls, Indicators, and Connectors

The ASAP 2020 Confirm software is accessed by three different levels of users:
• Administrator: installs and maintains software and updates, establishes user accounts
and rights (the Administrator responsibilities are covered in a separate manual).
• Developer: has access to all functions of the software. A Developer's primary function
is to create templates for an Analyst.
• Analyst: creates sample files from predefined templates; some fields, such as the Mass
field, are enabled and can be edited. An Analyst is also allowed to perform other tasks
as designated throughout this manual. Tasks not allowed are disabled.
This manual is written for the Developer and Analyst levels of the ASAP 2020 Confirm
software. Functions for the Administrator level are covered in the Administrator Utility User's
Guide.
This chapter contains information to familiarize you with the hardware and software of the
ASAP 2020 system. It is recommended that you read this chapter before attempting to operate
the ASAP 2020 system.
Controls, Indicators, and Connectors
This section contains a description of the controls, indicators, and connectors located on the
front, side, and rear panels of the ASAP 2020 system.
