All the memory map areas that are not allocated to on-chip memories and peripherals are

considered "Reserved". For the detailed mapping of available memory and register areas.

The following table gives the boundary addresses of the peripherals available in the

Boundary address

0xA000 0000 - 0xA000 0FFF

0xA000 1000 - 0xA000 1FFF

0x5005 0000 - 0x5005 03FF

0x5000 0000 - 0x5003 FFFF

0x4004 0000 - 0x4007 FFFF

0x4002 6400 - 0x4002 67FF

0x4002 6000 - 0x4002 63FF

0x4002 4000 - 0x4002 4FFF

0x4002 3C00 - 0x4002 3FFF

0x4002 3800 - 0x4002 3BFF

0x4002 3000 - 0x4002 33FF

0x4002 1C00 - 0x4002 1FFF

0x4002 1800 - 0x4002 1BFF

0x4002 1400 - 0x4002 17FF

0x4002 1000 - 0x4002 13FF

0x4002 0C00 - 0x4002 0FFF

0x4002 0800 - 0x4002 0BFF

0x4002 0400 - 0x4002 07FF

0x4002 0000 - 0x4002 03FF

0x4001 5C00 - 0x4001 5FFF

0x4001 5800 - 0x4001 5BFF

0x4001 4800 - 0x4001 4BFF

0x4001 4400 - 0x4001 47FF

0x4001 4000 - 0x4001 43FF

0x4001 3C00 - 0x4001 3FFF

0x4001 3800 - 0x4001 3BFF

0x4001 3400 - 0x4001 37FF

Table 1. STM32F446xx register boundary addresses

FMC control register

QUADSPI register

Flash interface

RM0390 Rev 4

Section 11.8: FMC register map on page 323

Section 12.5.14: QUADSPI register map on

Section 15.7.12: DCMI register map on page 448

Section 31.15.61: OTG_FS/OTG_HS register map

on page 1191

Section 31.15.61: OTG_FS/OTG_HS register map

on page 1191

Section 9.5.11: DMA register map on page 234

Section 3.8: Flash interface registers on page 80

Section 6.3.28: RCC register map on page 172

Section 4.4.4: CRC register map on page 91

Section 7.4.11: GPIO register map on page 193

Section 28.5.10: SAI register map on page 973

Section 18.5.12: TIM10/11/13/14 register map on

Section 10.3.7: EXTI register map on page 249

Section 8.2.9: SYSCFG register maps on

Section 26.7.10: SPI register map on page 896
