RM0390
Bits 31:7 Reserved, must be kept at reset value.
Bit 6 CLFSDET: Clear late frame synchronization detection flag.
This bit is write only.
Programming this bit to 1 clears the LFSDET flag in the SAI_xSR register.
This bit is not used in AC'97or SPDIF mode
Reading this bit always returns the value 0.
Bit 5 CAFSDET: Clear anticipated frame synchronization detection flag.
This bit is write only.
Programming this bit to 1 clears the AFSDET flag in the SAI_xSR register.
It is not used in AC'97or SPDIF mode.
Reading this bit always returns the value 0.
Bit 4 CCNRDY: Clear Codec not ready flag.
This bit is write only.
Programming this bit to 1 clears the CNRDY flag in the SAI_xSR register.
This bit is used only when the AC'97 audio protocol is selected in the SAI_xCR1 register.
Reading this bit always returns the value 0.
Bit 3 Reserved, must be kept at reset value.
Bit 2 CWCKCFG: Clear wrong clock configuration flag.
This bit is write only.
Programming this bit to 1 clears the WCKCFG flag in the SAI_xSR register.
This bit is used only when the audio block is set as master (MODE[1] = 0) and NODIV = 0 in the
SAI_xCR1 register.
Reading this bit always returns the value 0.
Bit 1 CMUTEDET: Mute detection flag.
This bit is write only.
Programming this bit to 1 clears the MUTEDET flag in the SAI_xSR register.
Reading this bit always returns the value 0.
Bit 0 COVRUDR: Clear overrun / underrun.
This bit is write only.
Programming this bit to 1 clears the OVRUDR flag in the SAI_xSR register.
Reading this bit always returns the value 0.
28.5.9

Data register (SAI_ADR / SAI_BDR)

Address offset: block A: 0x020
Address offset: block B: 0x040
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
24 23 22 21
DATA[31:16]
rw rw rw rw
8 7 6 5
DATA[15:0]
rw rw rw rw
RM0390 Rev 4
Serial audio interface (SAI)
20 19 18 17
rw rw rw rw
4 3 2 1
rw rw rw rw
16
rw
0
rw
