SPDIF receiver interface (SPDIFRX)
27.5.5

Data input register (SPDIFRX_DR)

Address offset: 0x10
Reset value: 0x0000 0000
This register can take 3 different formats according to DRFMT. Here is the format when
DRFMT = 0b00:
31 30 29
Res. Res. PT[1:0]
r
15 14 13
r r r
Bits 31:30 Reserved, must be kept at reset value.
Bits 29:28 PT[1:0]: Preamble Type
These bits indicate the preamble received.
00: not used
01: Preamble B received
10: Preamble M received
11: Preamble W received
Note that if PTMSK = 1, this field is forced to zero
Bit 27 C: Channel Status bit
Contains the received channel status bit, if CUMSK = 0, otherwise it is forced to 0
Bit 26 U: User bit
Contains the received user bit, if CUMSK = 0, otherwise it is forced to 0
Bit 25 V: Validity bit
Contains the received validity bit if VMSK = 0, otherwise it is forced to 0
Bit 24 PE: Parity Error bit
Contains a copy of PERR bit if PMSK = 0, otherwise it is forced to 0
Bits 23:0 DR[23:0]: Data value
Contains the 24 received data bits, aligned on D[23]
924/1328
28 27 26 25
C U V
r r r r
12 11 10 9
r r r r
24 23 22
PE
r r r
8 7 6
DR[15:0]
r r r
RM0390 Rev 4
21 20 19 18
DR[23:16]
r r r r
5 4 3 2
r r r r
RM0390
17 16
r r
1 0
r r
