ST STM32F446 Series Reference Manual page 304

Flexible memory controller (FMC)
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:24 ATTHIZ[7:0]: Attribute memory data bus Hi-Z time
Defines the number of HCLK clock cycles during which the data bus is kept in Hi-Z after the
start of a NAND Flash write access to attribute memory space on socket. Only valid for writ
transaction:
0000 0000: 0 HCLK cycle
1111 1110: 255 HCLK cycles
1111 1111: reserved.
Bits 23:16 ATTHOLD[7:0]: Attribute memory hold time
Defines the number of HCLK clock cycles for write access and HCLK (+2) clock cycles for
read access during which the address is held (and data for write access) after the command
deassertion (NWE, NOE), for NAND Flash read or write access to attribute memory space
on socket:
0000 0000: reserved
0000 0001: 1 HCLK cycle for write access / 3 HCLK cycles for read access
1111 1110: 254 HCLK cycles for write access / 256 HCLK cycles for read access
1111 1111: reserved.
Bits 15:8 ATTWAIT[7:0]: Attribute memory wait time
Defines the minimum number of HCLK (+1) clock cycles to assert the command (NWE,
NOE), for NAND Flash read or write access to attribute memory space on socket x. The
duration for command assertion is extended if the wait signal (NWAIT) is active (low) at the
end of the programmed value of HCLK:
0000 0000: reserved
0000 0001: 2 HCLK cycles (+ wait cycle introduced by deassertion of NWAIT)
1111 1110: 255 HCLK cycles (+ wait cycle introduced by deasserting NWAIT)
1111 1111: reserved.
Bits 7:0 ATTSET[7:0]: Attribute memory setup time
Defines the number of HCLK (+1) clock cycles to set up address before the command
assertion (NWE, NOE), for NAND Flash read or write access to attribute memory space on
socket:
0000 0000: 1 HCLK cycle
1111 1110: 255 HCLK cycles
1111 1111: reserved.
304/1328
28 27 26 25
ATTHIZ
rw rw rw rw
12 11 10 9
ATTWAIT
rw rw rw rw
24 23 22
rw rw rw
8 7 6
rw rw rw
RM0390 Rev 4
21 20 19 18
ATTHOLD
rw rw rw rw
5 4 3 2
ATTSET
rw rw rw rw
RM0390
17 16
rw rw
1 0
rw rw
