RM0390
As soon as the FMC_SDRTR register is programmed, the timer starts counting. If the value
programmed in the register is '0', no refresh is carried out. This register must not be
reprogrammed after the initialization procedure to avoid modifying the refresh rate.
Each time a refresh pulse is generated, this 13-bit COUNT field is reloaded into the counter.
If a memory access is in progress, the Auto-refresh request is delayed. However, if the
memory access and Auto-refresh requests are generated simultaneously, the Auto-refresh
takes precedence. If the memory access occurs during a refresh operation, the request is
buffered to be processed when the refresh is complete.
This register is common to SDRAM bank 1 and bank 2.
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
REIE
rw
rw
Bits 31: 15 Reserved, must be kept at reset value
Bit 14 REIE: RES Interrupt Enable
0: Interrupt is disabled
1: An Interrupt is generated if RE = 1
Bits 13:1 COUNT[12:0]: Refresh Timer Count
This 13-bit field defines the refresh rate of the SDRAM device. It is expressed in number of memory
clock cycles. It must be set at least to 41 SDRAM clock cycles (0x29).
Refresh rate = (COUNT + 1) x SDRAM frequency clock
COUNT = (SDRAM refresh period / Number of rows) - 20
Bit 0 CRE: Clear Refresh error flag
This bit is used to clear the Refresh Error Flag (RE) in the Status Register.
0: no effect
1: Refresh Error flag is cleared
Note:
The programmed COUNT value must not be equal to the sum of the following timings:
TWR+TRP+TRC+TRCD+4 memory clock cycles .
SDRAM Status register (FMC_SDSR)
Address offset: 0x158
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:5 Reserved, must be kept at reset value
28
27
26
25
Res.
Res.
Res.
12
11
10
9
rw
rw
rw
rw
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
8
7
6
COUNT
rw
rw
rw
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
BUSY
RM0390 Rev 4
Flexible memory controller (FMC)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
rw
rw
rw
rw
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
MODES2
MODES1
r
r
r
r
17
16
Res.
Res.
1
0
CRE
rw
w
17
16
Res.
Res.
1
0
RE
r
r
321/1328
