SDRAM Controller Operation
15.2.2.3 DRAM Controller Mask Registers (DMR0/DMR1)
The DMRn, Figure 15-4, includes mask bits for the base address and for address attributes.
31
Field
Reset
R/W
Addr
Figure 15-4. DRAM Controller Mask Registers (DMRn)
Table 15-6 describes DMRn fields.
Bits
Name
31–18
BAM
Base address mask. Masks the associated DACRn[BA]. Lets the DRAM controller connect to various DRAM
sizes. Mask bits need not be contiguous (see Section 15.3, "SDRAM Example.")
0 The associated address bit is used in decoding the DRAM hit to a memory block.
1 The associated address bit is not used in the DRAM hit decode.
17–9
—
Reserved, should be cleared.
8
WP
Write protect. Determines whether the associated block of DRAM is write protected.
0 Allow write accesses
1 Ignore write accesses. The DRAM controller ignores write accesses to the memory block and an address
exception occurs. Write accesses to a write-protected DRAM region are compared in the chip select module for
a hit. If no hit occurs, an external bus cycle is generated. If this external bus cycle is not acknowledged, an access
exception occurs.
7
—
Reserved, should be cleared.
6–1
AMx
Address modifier masks. Determine which accesses can occur in a given DRAM block.
0 Allow access type to hit in DRAM
1 Do not allow access type to hit in DRAM
Bit
C/I CPU space/interrupt acknowledge
AM Alternate master
SC
SD Supervisor data
UC User code
UD User data
0
V
Valid. Cleared at reset to ensure that the DRAM block is not erroneously decoded.
0 Do not decode DRAM accesses.
1 Registers controlling the DRAM block are initialized; DRAM accesses can be decoded.
15-8
18 17
BAM
IPSBAR + 0x04C (DMR0), 0x054 (DMR1)
Table 15-6. DMRn Field Descriptions
Associated Access Type
Supervisor code
MCF5282 User's Manual
9
8
—
WP — C/I AM SC SD UC UD V
Uninitialized
R/W
Description
MOVEC instruction or interrupt acknowledge cycle
DMA master
Any supervisor-only instruction access
Any data fetched during the instruction access
Any user instruction
Any user data
7
6
5
4
3
2
Access Definition
MOTOROLA
1
0
0
