GENERAL INFORMATION

SERVICE RULES

GENERAL INFORMATION
1. Use genuine Honda or Honda-recommended parts and lubricants or their equivalents. Parts that do not meet Honda's
design specifications may cause damage to the scooter.
2. Use the special tools designed for this product to avoid damage and incorrect assembly.
3. Use only metric tools when servicing the scooter. Metric bolts, nuts and screws are not interchangeable with English
fasteners.
4. Install new gaskets, O-rings, cotter pins, and lock plates when reassembling.
5. When tightening bolts or nuts, begin with the larger diameter or inner bolt first. Then tighten to the specified torque
diagonally in incremental steps unless a particular sequence is specified.
6. Clean parts in cleaning solvent upon disassembly. Lubricate any sliding surfaces before reassembly.
7. After reassembly, check all parts for proper installation and operation.
8. Route all electrical wires as shown in the Cable and Harness Routing (page 1-21).
9. Do not bend or twist control cables. Damaged control cables will not operate smoothly and may stick or bend.
ABBREVIATION
Throughout this manual, the following abbreviations are used to identify the respective parts or systems.
Abbrev. term
ABS
CBS
CKP sensor
DLC
DTC
ECM (NSS250S)
ECT sensor
EEPROM
EM connector
EOP switch
HDS
IACV
IAT sensor
MAP sensor
MIL
PAIR
PCM (NSS250A)
PGM-FI
SCS connector
TP sensor
VS sensor
1-2
maxiscooter-club.ru
Full term
Anti-lock Brake System
Combined Brake System
Crankshaft Position sensor
Data Link Connector
Diagnostic Trouble Code
Engine Control Module
Engine Coolant Temperature sensor
Electrically Erasable Programmable Read Only Memory
Emergency Mode connector
Engine Oil Pressure switch
Honda Diagnostic System
Idle Air Control Valve
Intake Air Temperature sensor
Manifold Absolute Pressure sensor
Malfunction Indicator Lamp
Pulsed Secondary Air Injection
Powertrain Control Module
Programmed Fuel Injection
Service Check Short connector
Throttle Position sensor
Vehicle Speed sensor
