  • Page 1 OWNER’S MANUAL NSC110MPD...
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Congratulations on your purchase of a new The following codes in this manual ● Honda scooter. Your selection of a Honda indicate each country. makes you part of a worldwide family of The illustrations here in are based on the ●...
  • Page 4 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this scooter safely is an You WILL be KILLED or SERIOUSLY HURT important responsibility. if you don’t follow instructions. To help you make informed decisions about WARNING safety, we have provided operating procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Scooter Safety P. 2 Operation Guide P. 18 Maintenance P. 44 Troubleshooting P. 80 Information P. 96 Specifications P. 107 Index P. 110...

  • Page 6: Scooter Safety

    Scooter Safety This section contains important information for safe riding of your scooter. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 6 Safety Precautions..........P. 11 Riding Precautions ..........P. 12 Accessories & Modifications......P. 16 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines that you and your passenger are both wearing an approved motorcycle helmet and protective Follow these guidelines to enhance your safety: apparel. Instruct your passenger on holding Perform all routine and regular inspections onto the grab rail or your waist, leaning with ●...
  • Page 8 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your scooter properly by wearing bright reflective clothing, positioning maintained and in safe riding condition. yourself so other drivers can see you, signaling...
  • Page 9 Safety Guidelines If you decide to continue riding, first turn the Never run your scooter inside a garage or other ignition switch to the (Off) position, and enclosure. evaluate the condition of your scooter. Inspect WARNING for fluid leaks, check the tightness of critical nuts Running the engine of your scooter and bolts, and check the handlebar, control levers, brakes, and wheels.

  • Page 10: Image Labels

    Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
  • Page 11 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
  • Page 12 • The luggage weight must not exceed 15 kg (33 lb) under any circumstances. • The fitting of large fork-mounted or large handlebar mounted fairing is not recommended. CBS CAUTION LABEL Cable adjustment must be done by Honda dealer.
  • Page 13 Image Labels TYRE INFORMATION LABEL Cold tyre pressure: [Driver only] Front 200 kPa (2.00 kgf/cm , 29 psi) Rear 225 kPa (2.25 kgf/cm , 33 psi) [Driver and passenger] Front 200 kPa (2.00 kgf/cm , 29 psi) Rear 225 kPa (2.25 kgf/cm , 33 psi) Tyre size: Front...
  • Page 14 Image Labels SAFETY REMINDER LABEL For your protection, always wear helmet, protective apparel. FUEL LABEL Unleaded petrol only ETHANOL up to 10 % by volume CARGO LIMIT LABEL Do not exceed 10 kg (22 lb). CARGO LIMIT LABEL Do not exceed 1.5 kg (3.3 lb). REAR CARRIER LABEL Do not exceed 3.0 kg (6.6 lb).

  • Page 15: Safety Precautions

    Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● WARNING handlebar and feet on the floor. Keep passenger's hands onto the grab rail Not wearing a helmet increases the ●...

  • Page 16: Riding Precautions

    Riding Precautions Riding Precautions Exercise caution on low traction surfaces. ● The tyres slip more easily on such surfaces and braking distances are Running-in Period longer. During the first 500 km (300 miles) of running, Avoid continuous braking. ● follow these guidelines to ensure your scooter's Repeated braking, such as when future reliability and performance.
  • Page 17 Riding Precautions Wet or Rainy Conditions Parking Road surfaces are slippery when wet, and wet Park on a firm, level surface. ● brakes further reduce braking efficiency. If you must park on a slight incline or loose ● Exercise extra caution when braking in wet surface, park so that the scooter cannot conditions.
  • Page 18 Riding Precautions Parking with the Side Stand or Centre Left handle grip Stand Stop the engine. Using the side stand Push the side stand down. Slowly lean the scooter to the left until its Centre stand weight rests on the side stand. Using the centre stand To lower the centre stand, stand on the left Grab rail...
  • Page 19 Riding Precautions Refuelling and Fuel Guidelines Follow these guidelines to protect the engine, fuel system and catalytic converter: Use only unleaded petrol. ● Use recommended octane number. Using ● lower octane petrol will result in decreased engine performance. Do not use fuels containing a high ●...

  • Page 20: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your scooter by Honda or make Follow all instructions in this owner's modifications to your scooter from its original manual regarding accessories and design.

  • Page 21: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your scooter's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.

  • Page 22: Operation Guide

    Basic Operation Flow Pre-ride Inspection (P.49) Acceleration Carefully inspect your scooter to (P.35) make sure that it is safe to ride. Apply throttle gradually. Obey the speed limit. Starting the Engine (P.32) Start and warm the engine. Avoid revving the engine. Starting the How to use basic features.
  • Page 23 Parking Braking (P.13) (P.36) Close the throttle and apply the front and rear brakes together. Park on a firm level surface. The brakelight will indicate Use the stand, and lock the that you have applied the steering and close the shutter. brakes.
  • Page 24 Parts Location Document bag (P.41) Throttle grip (P.77) Front brake fluid reservoir (P.71) Front brake lever Shopping hook (P.42) Inner rack (P.43) Battery (P.61) Fuse box (P.94) Helmet holder (P.40) Spark plug (P.64) Centre compartment (P.41) Engine oil drain bolt (P.68) Engine oil fill cap/dipstick (P.67)
  • Page 25 Rear brake lock lever (P.28) Rear brake lever (P.72) Helmet holder (P.40) Seat (P.39) Fuel fill cap (P.37) Tool kit (P.60) Inner rack (P.43) Crankcase breather (P.78) Oil plug (P.68) Centre stand (P.14) Side stand (P.76)
  • Page 26 Instruments Fuel gauge Needle in the red mark, remaining fuel approximately 1.3 L (0.34 US gal, 0.29 Imp gal) Speedometer This shows your speed in kilometer per hour (km/h) and/or miles per hour (mph) depend on type. Odometer Total distance ridden.
  • Page 27 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Turn signal indicator High beam indicator PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned to the (On) position. If it comes on while engine is running: (P.82)
  • Page 28 Switches Idling stop switch Switches the Idling Stop system on/off. • IDLING STOP : The Idling Stop system is on. • IDLING : The Idling Stop system is off. Idling Stop system: (P.29) Turn signal switch Start button Pressing the switch turns the turn signal off.
  • Page 29 (On) Ignition switch Turns electrical system on for starting/riding. Switches the electrical system on/off, SEAT locks the steering, and operates the Operates the seat opener switch. seat opener switch. (Off) Key can be removed when in the (Off) Turns engine off. (Lock) position.
  • Page 30 Switches (Continued) Steering Lock Locking Turn the handlebar all the way to the left or Lock the steering when parking to help right. prevent theft. Push the key down, and turn the ignition A U-shaped wheel lock or similar device is switch to the (Lock) position.
  • Page 31 Shutter Close Remove the ignition key from the ignition The ignition switch for this scooter is switch. equipped with a shutter. After parking the Align the projection of the shutter key with scooter, close the shutter for theft the slot of the shutter, and turn the shutter prevention.
  • Page 32 Rear Brake Lock Be sure the rear brake lock is applied while Unlocking starting and warming up the engine. Squeeze the rear brake lever. Before riding, make sure that the rear brake Locking lock is fully released so there is no drag on Squeeze the rear brake lever and set the rear the rear wheel.
  • Page 33 Idling Stop System Idling Stop system is designed to help reduce Activation of the Idling Stop System the fuel consumption and noise, by idling The Idling Stop system becomes ready to stop the engine and Idling Stop indicator stop while making a stop such as waiting at comes on when the following requirements an intersection.
  • Page 34 Idling Stop System (Continued) Stopping the engine by the Idling Stop Safety Precaution for the Idling Stop System System Do not go away from the scooter while the The engine stops and Idling Stop indicator Idling Stop indicator is flashing. When you go changes to flash after you close the throttle away from the scooter, always turn the completely and stop the scooter while the...
  • Page 35 Restarting the Engine NOTICE Check that the Idling Stop indicator is Headlight stays on after the engine is stopped by the Idling Stop system. The battery may flashing, and then open the throttle. discharge and you may not be able to restart If it is not flashing, you can't restart the engine.
  • Page 36 Starting the Engine Start your engine using the following procedure, Consult your dealer for advice if you plan to regardless of whether the engine is cold or warm. ride your scooter at an altitude above 2,500 m (8,000 feet). This scooter is equipped with a side stand NOTICE ignition cut-off system.
  • Page 37 Place the scooter on its centre stand. Turn the ignition switch to the (On) Lock the rear wheel by squeezing the rear position. brake lever and setting the rear brake lock Confirm the following: lever. • The PGM-FI malfunction indicator The starter motor will only work when lamp (MIL) is off.
  • Page 38 Starting the Engine (Continued) If you cannot start the engine: With the throttle completely closed, press With the throttle slightly open (about 3 mm the start button. without freeplay) while starting the engine. Release the start button as soon as the About 3 mm, without freeplay engine starts.
  • Page 39 Riding Starting the Scooter Acceleration and deceleration To accelerate: Open the throttle slowly. Push the scooter forward off the centre stand. To decelerate: Close the throttle. Lock the rear brake lock. Keep throttle closed. Open Close Make sure the side stand and centre stand (Accelerate) (Decelerate) are up.
  • Page 40 Riding (Continued) Braking Close the throttle and apply the front and rear brake levers together. Do not apply the brake lock while riding. It may cause the wheel to lock, reducing control of the scooter. Rear brake lever Front brake lever...
  • Page 41 Refuelling Fuel type: Unleaded petrol only Arrow marks Fuel fill cap Fuel octane number: Your scooter is designed to use Research Octane Number (RON) 91 or higher. Tank capacity: 5.2 L (1.37 US gal, 1.14 Imp gal) Refuelling and Fuel Guidelines (P.15) Lower edge of filler neck...
  • Page 42 Refuelling (Continued) Closing the Fuel Fill Cap Install and tighten the fuel fill cap firmly by turning it clockwise. Make sure that the arrow marks on the fuel fill cap and fuel tank are aligned. Close the seat. WARNING Petrol is highly flammable and explosive.
  • Page 43 Storage Equipment Seat Open Seat Turn the handlebar pointed straight ahead. Insert the ignition key and turn it to the position of SEAT. Push the SEAT side of the seat opener switch. Open the seat. Seat Close Close and push down on the rear of the seat until locks.
  • Page 44 Storage Equipment (Continued) Helmet Holder WARNING The helmet holders are located under the Riding with a helmet attached to the seat. holder can interfere with your ability to Use the helmet holders only when parked. safely operate the scooter and could lead to a crash in which you can be Helmet holders seriously hurt or killed.
  • Page 45 A helmet can be stored in the centre Document Bag compartment. The document bag is in the document Set in the front of the helmet forward. compartment on the reverse side of the seat. Some helmets may not fit in the Document compartment due to their size or design.
  • Page 46 Storage Equipment (Continued) Tool Kit Shopping Hook The tool kit is in the centre compartment. The shopping hook is provided below the handlebar. Tool kit Do not attach large luggage to the hook that would hang out from the scooter and/or interfere with the movement of your feet.
  • Page 47 Inner Rack Rear Carrier The inner racks are provided below the Never exceed the maximum weight limit. handlebar. Maximum Weight: 3.0 kg (6.6 lb) Rear carrier Inner racks The maximum allowable load on the shopping hook and the inner racks shall be no more than 1.5 kg (3.3 lb).

  • Page 48: Maintenance

    Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ......P. 45 Other Adjustments..........P. 79 Maintenance Schedule........P. 46 Adjusting the Headlight Aim ......P. 79 Maintenance Fundamentals ......

  • Page 49: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your scooter well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task, and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.

  • Page 50: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your scooter after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 51 Inspect (clean, adjust, lubricate, or replace, if necessary) have the necessary tools and are mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your scooter serviced by your dealer.
  • Page 52 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 49 × 1,000 mi Final Drive Oil 2 Years – Battery Brake Fluid 2 Years Brake Shoes/Pads Wear 72, 75 Brake System Brake Lock Operation Headlight Aim Lights/Horn –...

  • Page 53: Maintenance Fundamentals

    Maintenance Fundamentals Brakes - Check operation; Pre-ride Inspection ● Front: check brake fluid level and pads wear. To ensure safety, it is your responsibility to P. 71, P. 72 perform a pre-ride inspection and make sure Rear: check shoes wear and freeplay, adjust that any problem you find is corrected.
  • Page 54 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your scooter unsafe and cause a crash When ordering coloured components, specify in which you can be seriously hurt or the model name, colour, and code mentioned killed.
  • Page 55 Maintenance Fundamentals Battery NOTICE Your battery is a maintenance-free type and can Your scooter has a maintenance-free type be permanently damaged if the cap strip is battery. You do not have to check the battery removed. electrolyte level or add distilled water. Clean the battery terminals if they become dirty or This symbol on the battery means corroded.
  • Page 56 Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
  • Page 57 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
  • Page 58 Selecting the Engine Oil circular API service symbol. For recommended engine oil, see “Specifications.” P. 108 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MB ●...
  • Page 59 If the drain tube overflows, the air filter may Brake fluid can damage plastic and painted become contaminated with engine oil causing surfaces. poor engine performance. P. 78 Wipe up spills immediately and wash thoroughly. Recommended brake fluid: Honda DOT 3 or DOT 4 Brake Fluid or equivalent...
  • Page 60 Maintenance Fundamentals Inspecting for Abnormal Wear Tyres (Inspecting/Replacing) Checking the Air Pressure Inspect the tyres for Visually inspect your tyres and use an air signs of abnormal wear pressure gauge to measure the air pressure at on the contact surface. least once a month or any time you think the tyres look low.
  • Page 61 Maintenance Fundamentals Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a crash in which you can be seriously hurt or killed.
  • Page 62 Maintenance Fundamentals Have your tyres replaced by your dealer. WARNING For recommended tyres and air pressure, see Installing improper tyres on your “Specifications.” P. 108 scooter can adversely affect handling Follow these guidelines whenever you replace and stability, and can cause a crash in tyres.
  • Page 63 Maintenance Fundamentals Air Cleaner This scooter is equipped with a viscous type air cleaner element. Air blow cleaning or any other cleaning can degrade the viscous element performance and cause the intake of dust. Do not perform the maintenance. Should be serviced by your dealer.

  • Page 64: Tool

    Tool The tool kit is in the centre compartment. P. 41 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. Standard/Phillips screwdriver ● Screwdriver handle ●...

  • Page 65: Removing & Installing Body Components

    Removing & Installing Body Components Battery Remove the bolt and unhook the battery holder. Disconnect the negative - terminal from Battery holder Battery the battery. Bolt Disconnect the positive + terminal from the battery. Remove the battery taking care not to drop the terminal nuts.

  • Page 66: Clip

    Removing & Installing Body Components Clip Clip Installation Removal Centre pin Press down on the centre pin to release Push the bottom of the centre pin. the lock. Insert the clip into the hole. Pull the clip out of the hole. Press down on the centre pin to lock the clip.

  • Page 67: Front Top Cover

    Removing & Installing Body Components Front Top Cover Front Top Cover Removal Remove the clips. P. 62 Front top cover Screws Remove the screws. Remove the front top cover while Slot carefully releasing the tabs from the slots. Tabs Be careful not to apply weight to the front top cover.

  • Page 68: Spark Plug

    Spark Plug Checking Spark Plug Centre cover Screws For the recommended spark plug, see “Specifications.” P. 108 Use only the recommended type of spark plug in the recommended heat range. NOTICE Using a spark plug with an improper heat range can cause engine damage.
  • Page 69 Spark Plug Checking Spark Plug Disconnect the spark plug cap from the Inspect the electrodes and centre spark plug. porcelain for deposits, erosion or carbon Clean any dirt from around the spark plug fouling. base. If the erosion or deposit is heavy, Remove the spark plug using a suitable replace the plug.
  • Page 70 Spark Plug Checking Spark Plug Check the spark plug gap using a wire- Tighten the spark plug: type feeler gauge. If the old plug is good: ● If adjustment is necessary, bend the 1/8 turn after it seats side electrode carefully. If installing a new plug, tighten it twice ●...

  • Page 71: Engine Oil

    Engine Oil Checking the Engine Oil Oil fill cap/dipstick Upper level Check the engine oil with the Idling Stop switch at IDLING. If the engine is cold, idle the engine for 3 to 5 minutes. Turn the ignition switch to the (Off) position and wait for 2 to 3 minutes.
  • Page 72 Engine Oil Adding Engine Oil Adding Engine Oil For the recommended oil and oil selection guidelines, see “Maintenance Fundamentals.” P. 54 If the engine oil is below or near the lower level mark, add the recommended engine oil. Changing Engine Oil, Cleaning P.
  • Page 73 Engine Oil Changing Engine Oil, Cleaning Strainer Screen Place your scooter on its centre stand on Sealing washer a firm, level surface. Place a drain pan under the drain bolt and oil plug. Remove the oil fill cap/dipstick, drain bolt and sealing washer to drain the oil.
  • Page 74 Engine Oil Changing Engine Oil, Cleaning Strainer Screen Install a new sealing washer onto the drain bolt. Tighten the drain bolt. Torque: 24 N·m (2.4 kgf·m, 18 lbf·ft) Fill the crankcase with the recommended oil ( P. 54, P. 108) and install the oil fill cap/dipstick.

  • Page 75: Brakes

    Brakes Checking the Front Brake Fluid Front brake fluid reservoir Place your scooter in an upright position on a firm, level surface. Check that the brake fluid reservoir is horizontal and that the fluid level is above the LOWER level mark. If the brake fluid level in the reservoir is below the LOWER level mark or the brake LOWER level...
  • Page 76 Brakes Inspecting the Front Brake Pads Inspecting the Front Brake Pads Always replace both left and right brake pads at the same time. Check the condition of the brake pad wear Inspecting the Rear Brake Lever indicators. Freeplay The pads need to be replaced if a brake pad is worn to the indicator.
  • Page 77 Brakes Adjusting the Rear Brake Lever Freeplay Adjusting the Rear Brake Lever Check the brake cable for kinks or signs of wear. If necessary have it replaced by your Freeplay dealer. Lubricate the brake cable with a Adjust the freeplay of the brake lever with the commercially available cable lubricant to front wheel pointed straight ahead.
  • Page 78 Brakes Adjusting the Rear Brake Lever Freeplay Adjust by turning the rear brake adjusting Push the brake arm to confirm that there nut a half-turn at a time. is a gap between the rear brake adjusting nut and brake arm pin. Brake arm pin Brake arm Increase...
  • Page 79 The rear brake is equipped with a brake wear the brake, the brake shoes must be replaced. indicator. See your dealer for this service. Brake panel Arrow When the brake service is necessary, see your dealer. Use only Honda Genuine Parts or its equivalent. Reference mark Brake arm...

  • Page 80: Side Stand

    Side Stand Checking the Side Stand Sit on the scooter and raise the side stand. Start the engine. Lower the side stand all the way. The engine should stop as you lower the side stand. If the engine doesn't stop, have your scooter inspected by your dealer.

  • Page 81: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the scooter inspected by your dealer.

  • Page 82: Crankcase Breather

    Crankcase Breather Cleaning the Crankcase Breather Place a suitable container under the crankcase breather tube. Remove the crankcase breather tube and drain deposits. Reinstall the crankcase breather tube. Crankcase breather tube...

  • Page 83: Other Adjustments

    Other Adjustments Adjusting the Headlight Aim You can adjust vertical aim of the headlight for proper alignment. To move the headlight case, loosen the bolt. Tighten the bolt after adjustment. Obey local laws and regulations. Headlight case Down Bolt...

  • Page 84: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 81 Burned-out Light Bulb........P. 87 Warning Indicators On........P. 82 Blown Fuse ............P. 94 PGM-FI (Programmed Fuel Injection) Unstable Engine Operation Occurs Malfunction Indicator Lamp (MIL)....P. 82 Intermittently ........... P. 95 When the Idling Stop System Does Not Operate Properly ..........

  • Page 85: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 32 sequence.

  • Page 86: Warning Indicators On

    Warning Indicators On PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) If the indicator comes on while riding, you may have a serious problem with the PGM-FI system. Reduce speed and have your scooter inspected by your dealer as soon as possible.

  • Page 87: When The Idling Stop System Does Not Operate Properly

    When the Idling Stop System Does Not Operate Properly Idling Stop Indicator Does Not If PGM-FI malfunction indicator lamp (MIL) lights: Come On When the PGM-FI malfunction indicator lamp (MIL) lights, the Idling Stop system does not When the Idling Stop indicator does not operate for protection of the engine.

  • Page 88: Engine Is Not Stopped By The Idling Stop System While The Idling Stop Indicator Is On

    When the Idling Stop System Does Not Operate Properly Engine is Not Stopped by the Idling Stop System While the Idling Stop Indicator is On Engine is Not Stopped by the Idling Stop System While the Idling Stop Indicator is On When the engine is not stopped by the Idling Stop system while the Idling Stop indicator is on, perform the followings.

  • Page 89: Engine Does Not Start Even If The Throttle Is Opened

    When the Idling Stop System Does Not Operate Properly Engine Does Not Start Even If the Throttle is Opened Engine Does Not Start Even If If the Idling Stop switch is at IDLING: While the engine is stopping by the Idling the Throttle is Opened Stop system, if you press the Idling Stop switch to IDLING, the Idling Stop system will...

  • Page 90: Tyre Puncture

    Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your scooter with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 91: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the scooter before Turn the ignition switch to the (Off) or charging.
  • Page 92 Electrical Trouble Burned-out Light Bulb Headlight Bulb Headlight case Socket Rearview mirrors Dust covers Mirror adapter Mirror Screws adapter Remove the front top cover. P. 63 Remove the screws. Pull up the dust covers. Remove the headlight case, then pull the Remove the rearview mirrors by removing socket off the bulb without turning it.
  • Page 93 Electrical Trouble Burned-out Light Bulb Do not touch the glass surface with your “TOP” mark fingers. If you touch the bulb with your bare hands, clean it with a cloth moistened with alcohol. Bulb Dust cover Remove the dust cover. Press the pin down and pull out the bulb without turning.
  • Page 94 Electrical Trouble Burned-out Light Bulb Position Light Bulb Turn the handlebar to the left (if removing the right side bulb) or right (if removing the left side bulb). Pull off the socket without turning. Pull out the bulb without turning. Install a new bulb and reinstall the parts in the reverse order of removal.
  • Page 95 Electrical Trouble Burned-out Light Bulb Brakelight/Taillight Bulb Remove the right and left turn signal covers. P. 93 Bulb Taillight lens Remove the rear lower cover. Remove the taillight lens and lens packing by removing the screws. Slightly press the bulb in and turn it Screws counterclockwise.
  • Page 96 Electrical Trouble Burned-out Light Bulb Front Turn Signal Bulb The right and left turn signal bulbs replacement can be done in the same way. Bulb Remove the front top cover. P. 63 Turn the socket counterclockwise, then pull it out. Pull out the bulb without turning.
  • Page 97 Electrical Trouble Burned-out Light Bulb Rear Turn Signal Bulb Turn signal cover Socket Bulb Clip Turn the socket counterclockwise, then pull it out. The right and left turn signal bulbs Pull out the bulb without turning. replacement can be done in the same way. Install a new bulb in the reverse order of Remove the clip.

  • Page 98: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Remove the front top cover. P. 63 Remove the fuse box cover. Pull the main fuse and other fuses out Before handling fuses, see “Inspecting and one by one with the fuse puller furnished Replacing Fuses.”...

  • Page 99: Unstable Engine Operation Occurs Intermittently

    Unstable Engine Operation Occurs Intermittently If the fuel pump filter is clogged, unstable engine operation will occur intermittently while riding. Even if this symptom occurs, you can continue to ride your scooter. If unstable engine operation occurs even if sufficient fuel is available, have your scooter inspected by your dealer as soon as possible.

  • Page 100: Information

    Information Keys............... P. 97 Instruments, Controls, & Other Features..P. 97 Caring for Your Scooter ........P. 98 Storing Your Scooter........P. 101 Transporting Your Scooter ......P. 102 You & the Environment ......... P. 103 Serial Numbers ..........P. 104 Fuels Containing Alcohol ......

  • Page 101: Keys

    Keys Keys Instruments, Controls, & Other Features Ignition Key Ignition Switch Be sure to record the key number provided with the key number plate. Store the spare key and Leaving the ignition switch in the (On) position key number in a safe location. with the engine stopped will drain the battery.

  • Page 102: Caring For Your Scooter

    Frequent cleaning and polishing is important to After the scooter dries, lubricate any moving ensure the life of your Honda. A clean scooter parts. makes it easier to spot potential problems.
  • Page 103 Caring for Your Scooter Do not direct water at the air cleaner: Washing Precautions ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
  • Page 104 Caring for Your Scooter Aluminium Components Panels Aluminium will corrode from contact with dirt, Follow these guidelines to prevent scratches mud, or road salt. Clean aluminium parts and blemishes: regularly and follow these guidelines to avoid Wash gently using a soft sponge and plenty ●...

  • Page 105: Storing Your Scooter

    Storing Your Scooter Storing Your Scooter After removing your scooter from storage, inspect all maintenance items required by the If you store your scooter outdoors, you should Maintenance Schedule. consider using a full-body motorcycle cover. If you won't be riding for an extended period, follow these guidelines: Wash your scooter and wax all painted ●...

  • Page 106: Transporting Your Scooter

    Transporting Your Scooter Transporting Your Scooter If your scooter needs to be transported, it should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform, and motorcycle tie-down straps. Never try to tow your scooter with a wheel or wheels on the ground.

  • Page 107: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a scooter can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 108: Serial Numbers

    Serial Numbers Serial Numbers Frame number The frame and engine serial numbers uniquely identify your scooter and are required in order to register your scooter. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.

  • Page 109: Fuels Containing Alcohol

    Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10% ethanol may: Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line. ●...

  • Page 110: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 111: Specifications

    Specifications Main Components ■ Displacement 108 cm (6.6 cu-in) Overall length 1,925 mm (75.8 in) Bore x stroke 50.0 x 55.1 mm (1.97 x 2.17 in) Overall width 690 mm (27.2 in) Compression ratio 9.5:1 Unleaded petrol Overall height 1,115 mm (43.9 in) Fuel Recommended: 91 RON or higher Wheelbase...
  • Page 112 0.12 L (0.13 US qt, 0.11 Imp qt) disassembly of use Snow Not Permitted Recommended Moped Not Permitted Honda DOT 3 or DOT 4 Brake Fluid brake fluid Tyre air Front 200 kPa (2.00 kgf/cm , 29 psi) pressure Rear 225 kPa (2.25 kgf/cm...
  • Page 113 Specifications Bulbs Torque Specifications ■ ■ Headlight 12 V-35/35 W Oil plug 20 N·m (2.0 kgf·m, 15 lbf·ft) Brakelight/Taillight 12 V-21/5 W Engine oil drain bolt 24 N·m (2.4 kgf·m, 18 lbf·ft) Front turn signal 12 V-10 W × 2 Rear turn signal 12 V-10 W ×...

  • Page 114: Index

    Index Document Bag..........41, 97 Accessories ............16 Owner’s Manual .......... 41, 97 Tool Kit..............42 Crankcase Breather ......... 78 Basic Operation Flow ........18 Battery............51, 61 Brakes Document Bag ........... 41, 97 Brake Lever Freeplay......... 72 Fluid ..............55, 71 Pad Wear .............
  • Page 115 Fuel Ignition Key............97 Gauge ..............22 Ignition Switch ........... 25, 97 Recommended ........... 37 Image Labels ............6 Remaining............22 Indicators ............23 Tank Capacity ............. 37 Inner Rack............43 Fuels Containing Alcohol......105 Instruments ............22 Fuses ............. 53, 94 Labels..............
  • Page 116 Engine ............54, 67 Safety Precautions........... 11 Seat ..............39 Serial Numbers..........104 Parking ............... 13 Shopping Hook ..........42 Parts Location........... 20 Shutter..............27 Petrol............ 15, 37, 107 Side Stand............76 PGM-FI (Programmed Fuel Injection) Side Stand Ignition Cut-off System ..32, 76 Malfunction Indicator Lamp (MIL)..
  • Page 117 Throttle............... 77 Tool Kit ............... 42 Transporting Your Scooter......102 Troubleshooting ..........80 Turn Signal Indicator ........23 Tyres Air Pressure ..........56, 108 Puncture............... 86 Replacing ............. 56 Warning Indicators On ........82 Washing Your Scooter........98 Weight Limit ............. 17...
  • Page 119 32K44L10 XXX.XXXX.XX.K 00X32-K44-L100 PRINTED IN XXXXX...
