CHAPTER 18 Core Entities
Item #
2
■
■
■
By default, configuration entities are displayed on the bottom border. To define the
position, use the 'Topology Location' parameter when configuring the entity, where
Down is the bottom border and Up the top border:
Configured SIP Interfaces. Each SIP Interface is displayed using the following "SIP
Interface"-titled icon, which includes the name and row index number:
If you hover your mouse over the icon, a pop-up appears displaying the following
basic information (example):
If you click the icon, a drop-down menu appears listing the following commands:
Edit: Opens a dialog box in the SIP Interfaces table to modify the SIP Interface.
Show List: Opens the SIP Interfaces table.
Delete: Opens the SIP Interfaces table where you are prompted to confirm
deletion of the SIP Interface.
To add a SIP Interface, do the following:
Description
