CHAPTER 52 Syslog and Debug Recording

"Total [ms (%)]"

Statistics per CPU core

Configuring Debug Recording

This section describes how to configure debug recording and how to collect debug recording

The procedure below describes how to configure the address of the debug recording server to

where the device sends the captured traffic. Once you configure an address, the device generates

debug recording packets for all calls. However, you can configure the device to generate debug

recording packets for specific calls, using Logging Filter rules in the Logging Filters table (see

Configuring Log Filter

To configure the debug recording server's address:

Open the Logging Settings page (Troubleshoot tab > Troubleshoot menu > Logging folder >

Logging Settings).

Total time (in msec) and percentage that task utilized CPU during

entire period.

Maximum lasting time (msec) that the task utilized CPU during

Context switch time - number of consecutive periods that were

allocated for this task.

Index of the CPU core.

Percentage of CPU utilization that occurred while executing at the

user level (application).

Percentage of CPU utilization that occurred while executing at the

user level with nice priority (Linux systems).

Percentage of CPU utilization that occurred while executing at the

system level (kernel).

Percentage of time that the CPU was idle (%) during which no

tasks were using the CPU core.

Percentage of time that the CPU was idle (5) during which tasks

were using the CPU core.

IRQ time (in percentage).

SoftIRQ time (in percentage%).

Debug recording is collected only on the device's OAMP interface.

For a detailed description of the debug recording parameters, see

Mediant 4000 SBC | User's Manual
