SLM-5650A Satellite Modem
Installation
2.3
Connect External Cables
Connect the cables to the proper locations on the rear panel.
See Chapter 3. REAR PANEL CONNECTORS
2.4
Configuration
All configurations are implemented locally via the unit's loaded firmware.
Step
Task
1
Read Chapter 5. FRONT PANEL OPERATION before continuing.
2
Connect the supplied power cable.
3
Set the power switch to ON.
The auto-sensing AC power supply does not require any adjustments
Do a check for the correct transmitter (Tx) and receiver (Rx) output signal levels and
4
spectrums.
5
Use the front panel keypad and display to configure the unit.
If there is any problem with installation or initial operation, read Appendix A.
TROUBLESHOOTING for possible solutions.
PINOUTS.
AND
2–7
Revision 8
MN-SLM5650A
