STEERING WHEEL AND COLUMN 6E – 13

UNIT REPAIR

STANDARD STEERING COLUMN

Disassembly Procedure
1. Remove the steering column from the vehicle. Refer
to "Steering Column" in this section.
Caution: Be careful not to impact on the steering
column shaft. Plastic sleeve may be broken that is
installed to secure the driver at the accident.
2. Remove the steering column shaft from the steering
column.
D Remove the retaining ring (1).
D Remove the washer (2).
D105A701
D Remove the spring (3).
D Remove the washer (4).
D Remove the locking of the alignment spacer (5).
D Push strongly the steering column shaft downward
(6).
D15A702A
D15A703A
