Daewoo MATIZ Service Manual page 411

DAEWOO M-150 BL2
Installation Procedure
1. Install the engine coolant temperature sensor.
Tighten
Tighten the engine coolant temperature sensor to
8–12 NSm (71–106 lb-ft).
D12F543B
INTAKE AIR TEMPERATURE (IAT)
SENSOR
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the intake air temperature (IAT) sensor.
D Disconnect the IAT sensor connector (1)
D Disconnect the IAT sensor.
D102F544
Installation Procedure
1. Install in the reverse order of removal.
2. Install the IAT sensor.
Tighten
Tighten the IAT sensor to 20–30 NSm (15–22 lb-ft).
20–30 NSm
D12F545A
ENGINE CONTROLS 1F – 313
