Application
Suspension Type
Shock Absorber
Stabilizer Shaft Diammeter
Coil Spring Height (No Load)
Grease Type (Front Wheel Bearing and Hub)
Application
Strut Assembly–to–Body Nuts
Strut Closure Nut
Strut Assembly–to–Knuckle Bolts
Control Arm Mounting Bolt
Control Arm Ball Stud Bolt
Stabilizer Shaft Castellated Nut
Stabilizer Shaft Mounting Bolt
Front Under Longitudinal Frame Bolts
Front Under Longitudinal Frame Nut
Drive Axle–to–Hub Caulking Nut
Crossmember Bolt
Strut Bar Bolts
ABS Front Speed Sensor Retaining Bolt
Wheel Hub–to–Brake Disc Bolt
DAEWOO M-150 BL2

SPECIFICATIONS

GENERAL SPECIFICATIONS

Maximum Length
Minimum Length
Stroke

FASTENER TIGHTENING SPECIFICATIONS

FRONT SUSPENSION 2C – 23
Unit
–
mm (in.) 475–481 (18.7–18.94)
mm (in.) 321–327 (12.64–12.87)
mm (in.)
mm (in.)
mm (in.)
– M–8143 ANTIF BRG GREASE
NSm
18 – 28
50 – 60
70 – 90
55 – 70
50 – 70
40 – 50
30 – 50
10 – 14
65 – 80
210
17 – 27
35 – 55
18 – 28
55 – 75
Description
Mcpherson (Strut)
154 (6.06)
24 (0.94)
374 (14.72 )
Lb-Ft Lb-In
13 – 21 –
36 – 44 –
52 – 66 –
41 – 52 –
36 – 52 –
30 – 36 –
22 – 36 –
– 89 – 124
48 – 59 –
155 –
13 – 20 –
25 – 41 –
13 – 21 –
41 – 55 –
