6E – 4 STEERING WHEEL AND COLUMN
DIAGNOSTIC INFORMATION AND PROCEDURES
Condition
Lock System Will Not
Unlock
Lock System Will Not
Lock
High Lock Effort
Key Cannot Be
Removed in the B
Position
Condition
Noise in the Column
High Steering Shaft
Effort
STEERING COLUMN DIAGNOSIS
Lock System
Probable Cause
D Damaged lock cylinder.
D The lack of free movement for the ignition
switch.
D Improper binding or damaged steering
column housing.
D Damaged lock cylinder.
D The lack of free movement for the ignition
switch.
D Improper binding or damaged steering
column housing.
D Damaged lock cylinder.
D The lack of free movement for the ignition
switch.
D Extreme misalignment of the housing to the
cover.
D The ignition switch to be set incorrectly.
D Damaged lock cylinder.
Probable Cause
D Improperly installed intermediate shaft–to–
column joints.
D Column misalignment.
D The lack of lubrication for the joint.
D The lack of lubrication for the steering shaft.
D Improperly seated shaft lock snap ring.
D Improperly installed intermediate shaft
pinch bolt.
D Column misalignment.
D A damaged bearing.
D The lack of free movement for the steering
shaft universal joint.
D Replace the lock cylinder.
D Lubricate the ignition switch.
D Remove the steering shaft and clear
D Replace the steering column
D Replace the lock cylinder.
D Lubricate the ignition switch.
D Remove the steering shaft and clear
D Replace the steering column
D Replace the lock cylinder.
D Lubricate the ignition switch.
D Realign the cover on the housing.
D Replace the cover as needed.
D Reset the ignition switch.
D Replace the lock cylinder.
Column
D Tighten the coupling pinch bolts.
D Replace the intermediate shaft as
D Replace the alignment spacer.
D Lubricate the joint.
D Lubricate the steering shaft bearing.
D Adjust the shaft lock snap ring.
D Replace the shaft lock snap ring as
D Tighten the pinch bolt.
D Replace the alignment spacer.
D Replace the steering column
D Lubricate the steering shaft
D Replace the steering column shaft
Correction
the steering column housing.
housing as needed.
the steering column housing.
housing as needed.
Correction
needed.
needed.
housing.
universal joint.
as needed.
DAEWOO M-150 BL2
