DAEWOO M-150 BL2
STEERING WHEEL AND COLUMN 6E – 9
Installation Procedure
1. Install the wiper switch.
2. Install the turn signal switch.
3. Install the steering column cover. Refer to "Steering
Column Cover" in this section.
4. Connect the negative battery cable.
D105A508

IGNITION SWITCH

Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the steering wheel. Refer to "Steering
Wheel" in this section.
3. Remove the ignition switch.
D Disconnect the electrical connector (1).
D Remove the screw (2).
D105A509
Installation Procedure
1. Connect the electrical connector.
2. Install the ignition switch with the screw.
3, Install the steering wheel. Refer to "Steering Wheel"
in this section.
4. Connect the negative battery cable.
D105A510
IGNITION LOCK CYLINDER WITH
IMMOBILIZER
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the steering wheel. Refer to "Steering
Wheel" in this section.
2. Disconnect the electrical connector for the immobiliz-
er detection coil.
3. Remove the lock cylinder.
D With the key in the ignition, turn to the position des-
D105A511 ignated I (1).
