DAEWOO M-150 BL2

REAR PARCEL SIDE SHELF

Removal Procedure
1. Disconnect the negative battery cable.
2. Open the tailgate.
3. Remove the seatback.
4. Remove the rear seat parcel shelf. Refer to "Rear
Parcel Shelf" in this section.
5. Remove the rear speaker from the rear parcel shelf.
Refer to Section 9F, Audio Systems.
6. Remove the rear parcel side shelf.
D Remove the screws (1).
D Remove the rear parcel side shelf (2).
D109E566
Installation Procedure
1. Install the rear parcel side shelf with the screw.
2. Install the rear speaker to the rear parcel shelf. Refer
to Section 9F, Audio Systems.
3. Install the rear parcel shelf. Refer to "Rear Parcel
Shelf" in this section.
4. Install the seatback.
5. Connect the negative battery cable.
D109E567
FRONT ROCKER TRIM PANEL
Removal Procedure
1. Pry off the rocker trim panel.
D Remove the clip (1).
D Remove the screw (2).
D Pry off the rocker trim panel (3).
D109E568
Installation Procedure
1. Install the rocker trim panel with the clip and the
screw.
D109E569
INTERIOR TRIM 9G – 13
