Rear Door Assembly - Daewoo MATIZ Service Manual

DAEWOO M-150 BL2
Installation Procedure
Notice: Dissimilar metals in direct contact with each
other may corrode rapidly. Make sure to use the correct
fastener to prevent premature corrosion.
1. Connect the body–to–door rubber grommet.
2. With the aid of another technician, lightly secure the
front door with the bolts.
3. Adjust the door for proper fit.
4. Tighten the hinge–to–body bolts.
5. Install the door hold open link with the bolt.
6. Install the fender. Refer to Section 9R, Body Front
D19C608A
End.
7. Connect the electrical connector.
8. Connect the negative battery cable.
9. Perform the waterleak test. Refer to Section 9I, Wa-
terleak.
10. Check for windnoise. Refer to Section 9J, Wind-
noise.

REAR DOOR ASSEMBLY

Removal Procedure
1. Disconnect the negative battery cable.
2. Pry off the lower B–pillar trim panel. Refer to Section
9G, Interior Trim.
3. Disconnect the rear door electrical connector.
a. Rear door electrical connector.
D109C609
4. Remove the rear door assembly.
D Remove the door hinge bolts (1).
D Remove the door hold open link bolt (2).
D Disconnect the body–to–door rubber grommet (3).
D Remove the rear door assembly (4).
D109C610
DOORS 9P – 21
