2C – 6 FRONT SUSPENSION

FRONT WHEEL BEARING

Bearing Axial End Play Inspection
1. Lift and suitably support the vehicle.
2. Inspect the end play of the bearing.
3. If excessive play is defeeted, free shoes from the disc
or remove the calipers.
4. Check the standard torque of the drive nut (spec. :
210 NSm (155 lb-ft)).
5. Check the bearing end play according to the following
method.
D Place a dial guage against the disc surface, grasp
the disc.
D Using a push–pull movement, note gage readings.
Specification
6. If the axial end play of the front wheel bearing exceed
0.130mm torque the drive shaft nut successively
(Max. allowance : 240 NSm (177 lb-ft))
D107B303
7. Check the axial end play again.
8. If the axial end play is above spec., replace the front
wheel bearing.
0.130mm Standard tighting torque
or less of drive shaft nut :
(0.005 in) 210 NSm (155 lb-ft)
DAEWOO M-150 BL2
