9P – 20 DOORS
4. Remove the window motor from the window regula-
tor.
D Remove the screws (1).
D Remove the window regulator (2).
Caution: Be careful what you are doing when sepa-
rating the window motor and the window regulator.
You may be hurt.
D109C604
Installation Procedure
1. Install the window motor to the window regulator with
the screws.
2. Install the window regulator assembly with the screws.
3. Connect the window motor electrical connector.
4. Install the glass. Refer to Section 9L, Glass and Mir-
rors.
5. Connect the negative battery cable.
D109C605

FRONT DOOR ASSEMBLY

Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the electrical connector under the instru-
ment panel.
Important: In case of the front passenger door, remove
the glove box in advance.
D109C606
3. Remove the fender. Refer to Section 9R, Body Front
End.
4. Remove the front door assembly.
D Remove the door hinge bolts (1).
D Remove the door hold open bolt (2).
D Disconnect the body–to–door rubber grommet (3).
D Remove the front door assembly (4).
D109C607
DAEWOO M-150 BL2
