Dtc 02 Driver Firing Circuit, Resistance Too Low - Daewoo MATIZ Service Manual

Step
1. Remove the driver airbag module.
2. Store the driver airbag module with the decorative
side facing upward.
3. Connect an ohmmeter to the terminals of the
wiring harness connector for the driver airbag
1
module.
D Refer to ''Diagnostic Illustration 3'' in this
section.
Does the ohmmeter show the specified value?
1. Replace the SDM.
2. Reconnect the negative battery cable.
2 3. Set the scan tool to CODE ERASE.
4. Do the diagnostic system check.
Does the code 02 still show as a current fault?
1. Replace the driver airbag module.
3 2. Reconnect the negative battery cable.
Is the repair complete?
1. Disconnect the clock spring wiring harness
connector at the lower steering column.
2. Connect an ohmmeter to the terminals at the
SDM side of the clock spring connector.
4
D Refer to ''Diagnostic Illustration 4'' in this
section.
Does the ohmmeter show the specified value?
1. Replace the clock spring.
5 2. Reconnect the negative battery cable.
Is the repair complete?
1. Replace the supplemental inflatable restraints
(SIR) wiring harness.
6
2. Reconnect the negative battery cable.
Is the repair complete?
DAEWOO M-150 BL2
SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 17
DTC 02 – Driver Firing Circuit, Resistance Too Low
Action Value(s) Yes
∞
Go to Step 2
– Go to Step 3
Go to
Diagnostic
System Check
–
∞
Go to Step 5
Go to
Diagnostic
System Check
–
Go to
Diagnostic
– System Check
No
Go to Step 4
System OK
–
Go to Step 6
–
–
