Daewoo MATIZ Service Manual page 504

DAEWOO M-150 BL2
MANUAL TRANSAXLE DRIVE AXLE 3B – 11
5. Remove the drive axle shaft boot.
D104B704
Assembly Procedure
1. Install in the reverse order of removal.
2. Install the joint assembly.
D Pre–install the joint assembly by pushing to the
drive axle shaft to widen the circlip.
D Keep the circlip widened (1).
D Push the joint assembly to the drive axle shaft (2).
D104B708
3. Fill the joint housing with recommended grease when
installing.
Capacity
Notice: Always use the recommended grease. If not,
joint and boot can be damaged.
Important: Always use new clamps.
D104B709
Inspection Procedure
1. Inspect the operation of joint.
2. Inspect for a leaking boot through the clamp side.
Important: Do not disassemble the outer joint assem-
bly. Parts are match fit and can not be serviced sepa-
rately. Improper reassembly will adversely affect both
performance and safety.
D104B710
80–90 g (2.8–3.2 ounces)
