23–28 NSm
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON–VEHICLE SERVICE
D109B528
D19B529A
D109B530
FRONT SEATS
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the front seat.
D Remove the bolts (1).
D Disconnect the seat belt warning lamp connector
(2).
D Remove the seat (3).
Installation Procedure
1. Connect the seat belt warning lamp connector.
2. Install the front seat with the bolts.
Tighten
Tighten the seat bolt to 23–28 NSm (17–21 lb-ft).
a. Seat bolt.
3. Connect the negative battery cable.
HEAD RESTRAINT
Removal Procedure
1. Pull the head restraint up to the stop position.
2. Insert a small flathead screwdriver in the notch in the
left guide sleeve and pull up the head restraint by
pushing the head restraint left.
SEATS 9H – 5
