9T – 28 IMMOBILIZER ANTI-THEFT SYSTEM
Installation Procedure
1. Install the detection coil by pressing it onto the lock
cylinder until it snaps in place.
2. Connect the two-pin connector to the immobilizer.
D29T002
3. Install the steering column covers with the screws.
Refer to Section 6E, Steering Wheel and Column.
D105A505
IMMOBILIZER CONTROL UNIT
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the steering column covers. Refer to Section
6E, Steering Wheel and Column.
D105A504
3. Slide the immobilizer control unit toward steering
wheel until it slides off its mounting bracket.
4. Disconnect the electrical connectors from the immo-
bilizer control unit (1).
D29T003
